Lined Prestressed Concrete Cylinder Pipe (PCCPL)
Classification:
Product Description
Single rubber ring lined prestressed concrete cylinder pipe (PCCPSL) basic size unit: mm
| Nominal inner diameter Do /(mm) |
Minimum Die Thickness tc /(mm) |
Minimum net thickness of protective layer /(mm) |
steel cylinder thickness ty /(mm) |
Bend depth C /(mm) |
Socket length E /(mm) |
Inner diameter of bell working face Bb /(mm) |
Outer diameter of socket working face Bs /(mm) |
Joint internal clearance J /(mm) |
Joint outer clearance K /(mm) |
Diameter of rubber ring d /(mm) |
Effective length Lo /(mm) |
Tube length L /(mm) |
Reference Weight /(t/m) |
| 400 | 40 | 25 | 1.5 | 93 | 93 | 493 | 493 | 15 | 15 | 20 | 5000 6000 |
5078 6078 |
0.23 |
| 500 | 40 | 593 | 593 | 0.28 | |||||||||
| 600 | 40 | 693 | 693 | 0.31 | |||||||||
| 700 | 45 | 803 | 803 | 0.41 | |||||||||
| 800 | 50 | 913 | 913 | 0.50 | |||||||||
| 900 | 55 | 1023 | 1023 | 0.60 | |||||||||
| 1000 | 60 | 1133 | 1133 | 0.70 | |||||||||
| 1200 | 70 | 1353 | 1353 | 0.94 | |||||||||
| 1400 | 90 | 1593 | 1593 | 1.35 |
Double rubber ring lined prestressed concrete cylinder pipe (PCCPDL) basic size unit: mm
| Nominal inner diameter Do /(mm) |
Minimum Die Thickness tc /(mm) |
Minimum net thickness of protective layer /(mm) |
steel cylinder thickness ty /(mm) |
Bend depth C /(mm) |
Socket length E /(mm) |
Inner diameter of bell working face Bb /(mm) |
Outer diameter of socket working face Bs /(mm) |
Joint internal clearance J /(mm) |
Joint outer clearance K /(mm) |
Diameter of rubber ring d /(mm) |
Effective length Lo /(mm) |
Tube length L /(mm) |
Reference Weight /(t/m) |
| 600 | 40 | 25 | 1.5 | 160 | 160 | 693 | 693 | 25 | 25 | 20 | 5000 6000 |
5135 6135 |
0.31 |
| 700 | 45 | 803 | 803 | 0.41 | |||||||||
| 800 | 50 | 913 | 913 | 0.50 | |||||||||
| 900 | 55 | 1023 | 1023 | 0.60 | |||||||||
| 1000 | 60 | 1133 | 1133 | 0.70 | |||||||||
| 1200 | 70 | 1353 | 1353 | 0.94 | |||||||||
| 1400 | 90 | 1593 | 1593 | 1.35 |
